Daemonless Reverse Proxy

Give every app on your network a real name with HTTPS: radarr.home.lan instead of 192.168.1.20:7878. Set up in a browser, no config files.

Your apps live at addresses like 192.168.1.20:7878, and every browser warns that they are "not secure". The reverse proxy gives each one a name, radarr.home.lan or radarr.example.com, with a padlock. You set it up from a web page, step by step, and add a name by pasting the address you use today. It is Caddy underneath, managed for you.

What it does

• A name and a padlock for every app. Paste where an app is; the proxy finds out whether it speaks HTTP or HTTPS and checks that it answers. Each name shows whether its app is up.
• Three kinds of names, your choice. Just for home (radarr.home.lan): free, works without the internet; the proxy is its own certificate authority, limited to your ending, and walks each phone and computer through trusting it once, with a QR code. A free name (radarr.you.duckdns.org) or your own domain (radarr.example.com): real certificates from Let's Encrypt, one wildcard for every name, renewed by itself; nothing to install on any device. It picks your DNS provider from the domain (Cloudflare, Route 53, DuckDNS, deSEC, Porkbun, Hetzner, OVH, Gandi, RFC 2136, acme-dns) and tries the token on Let's Encrypt's test service first.
• Home only, unless you say so. Every name opens only for devices on your home network. Open one to the internet when you want to; outsiders asking for any other name get nothing back, not even a "not found". On a host with several networks, you pick which are home: the proxy still reaches apps on the others.
• Short links. Type go/radarr in any browser on your network. go/ alone lists every name.
• Walks you through your router. Setup says exactly which record to add, with steps for OPNsense, pfSense, UniFi, Pi-hole, AdGuard Home and others, and turns green when it works.
• Says what is wrong, in plain words. A certificate that fails says why (token rejected, record never appeared, rate limit) and how to fix it. A name nobody set up shows a page saying so, at home.
• Works with fjord. Installed from fjord, it pairs by itself: fjord lists your apps that have no name yet, names them in one click, and keeps each name pointing at its app when the app moves to a new address.
• Scriptable. A key per app or script manages names and nothing else; there is an OpenAPI reference and a command line inside the container.
• Easy to keep. One encrypted backup file holds everything; restore it on a fresh install. Delete a name by mistake and Undo brings it back.

Native FreeBSD (amd64 and arm64), built from source. The web UI runs unprivileged; only Caddy is root, to bind ports 80 and 443.

Port	80
Registry	ghcr.io/daemonless/reverse-proxy
Source	https://github.com/daemonless/reverse-proxy
Website	https://daemonless.io/images/reverse-proxy/

Version Tags

Tag	Description	Best For
latest	daemonless Appliance. Managed Caddy reverse proxy with a web UI, built from source.	Most users — recommended.

Prerequisites

Before deploying, ensure your host environment is ready. See the Quick Start Guide for host setup instructions.

Deployment

Podman Compose

services:
  reverse-proxy:
    image: "ghcr.io/daemonless/reverse-proxy:latest"
    container_name: reverse-proxy
    environment:
      - PUID=1000  # User ID for the admin process (Caddy stays root to bind 80 and 443)
      - PGID=1000  # Group ID for the admin process
      - TZ=UTC  # Timezone for the container
      - RP_PAIRING_KEY=<RP_PAIRING_KEY>  # Admin only. A key (32+ random characters) an app that installed the proxy, such as fjord, uses to manage hosts; registered once as a connected app
      - RP_PAIRING_NAME=fjord  # Admin only. The connected app's name for RP_PAIRING_KEY. Default: Paired app
      - RP_PAIRING_ID=  # Admin only. The installing app's permanent id, so several of them are told apart. Optional.
      - RP_SETUP_TOKEN=<RP_SETUP_TOKEN>  # Admin only. First-run setup token chosen by the installing app, so it can open setup for you. Default: a new one in the log
      - RP_PAIRING_URL=  # Admin only. Where the installing app is opened, shown as a way back to it. Optional.
      # - RP_ADMIN_URL=  # Where you open the admin UI, e.g. https://192.168.1.5:8443. Optional: the proxy remembers the address you sign in at; this makes the first-run link exact before anyone has.
      # - RP_TRUST_PORT=  # Host port that reaches the HTTP trust page if you publish it on something other than 80. Optional.
      # - RP_DEBUG=  # Set to 1 for Caddy's full info-level log. Off by default so the log stays readable.
    volumes:
      - "/containers/reverse-proxy:/config"
      - "/containers/reverse-proxy/data:/data"
    ports:
      - "80:80"
      - "443:443"
      - "8443:8443"
    # always (not unless-stopped) so FreeBSD's podman rc.d auto-starts it at boot
    restart: always

Save as compose.yaml, then run podman-compose up -d.

AppJail Director

.env:

# .env

DIRECTOR_PROJECT=reverse-proxy
PUID=1000
PGID=1000
TZ=UTC
RP_PAIRING_KEY=<RP_PAIRING_KEY>
RP_PAIRING_NAME=fjord
RP_PAIRING_ID=
RP_SETUP_TOKEN=<RP_SETUP_TOKEN>
RP_PAIRING_URL=

appjail-director.yml:

# appjail-director.yml

options:
  - virtualnet: ':<random> default'
  - nat:
services:
  reverse-proxy:
    name: reverse_proxy
    options:
      - container: 'args:--pull'
      - expose: '80:80 proto:tcp'
      - expose: '443:443 proto:tcp'
      - expose: '8443:8443 proto:tcp'
    oci:
      user: root
      environment:
        - PUID: !ENV '${PUID}'
        - PGID: !ENV '${PGID}'
        - TZ: !ENV '${TZ}'
        - RP_PAIRING_KEY: !ENV '${RP_PAIRING_KEY}'
        - RP_PAIRING_NAME: !ENV '${RP_PAIRING_NAME}'
        - RP_PAIRING_ID: !ENV '${RP_PAIRING_ID}'
        - RP_SETUP_TOKEN: !ENV '${RP_SETUP_TOKEN}'
        - RP_PAIRING_URL: !ENV '${RP_PAIRING_URL}'
    volumes:
      - reverse-proxy: /config
      - reverse-proxy_data: /data
volumes:
  reverse-proxy:
    device: '/containers/reverse-proxy'
  reverse-proxy_data:
    device: '/containers/reverse-proxy/data'

Makejail:

# Makejail

ARG tag=latest

OPTION container=boot
OPTION overwrite=force
OPTION from=ghcr.io/daemonless/reverse-proxy:${tag}

Save the files above, then run appjail-director up.

Warning

Exposing ports in AppJail means that your service can be reached from remote hosts. If that is not your intention, do not expose the ports and communicate with the service using the jail's IPv4 address or hostname assigned by the virtual network.

To avoid exposing ports, just remove the expose option in your appjail-director.yml or from your command-line arguments.

Bastille

Warning

Bastille's OCI support is experimental. It requires buildah and shares the host network stack (inherit). Mount volumes with --volume HOST JAIL; without it, image-declared volumes are stored under ${bastille_volumesdir}/${jail}.

services:
  reverse-proxy:
    name: reverse-proxy
    image: "ghcr.io/daemonless/reverse-proxy:latest"
    network:
      - mode: host
    environment:
      - PUID=1000
      - PGID=1000
      - TZ=UTC
      - RP_PAIRING_KEY=<RP_PAIRING_KEY>
      - RP_PAIRING_NAME=fjord
      - RP_PAIRING_ID=
      - RP_SETUP_TOKEN=<RP_SETUP_TOKEN>
      - RP_PAIRING_URL=
    volumes:
      - "/containers/reverse-proxy:/config"
      - "/containers/reverse-proxy/data:/data"

Save as bastille-compose.yml, then run bastille up. Open http://<server>:80 from another machine (the server's own browser can't use a published port).

Parameters

Environment Variables

Variable	Default	Description
PUID	1000	User ID for the admin process (Caddy stays root to bind 80 and 443)
PGID	1000	Group ID for the admin process
TZ	UTC	Timezone for the container
RP_PAIRING_KEY	<RP_PAIRING_KEY>	Admin only. A key (32+ random characters) an app that installed the proxy, such as fjord, uses to manage hosts; registered once as a connected app
RP_PAIRING_NAME	fjord	Admin only. The connected app's name for RP_PAIRING_KEY. Default: Paired app
RP_PAIRING_ID	``	Admin only. The installing app's permanent id, so several of them are told apart. Optional.
RP_SETUP_TOKEN	<RP_SETUP_TOKEN>	Admin only. First-run setup token chosen by the installing app, so it can open setup for you. Default: a new one in the log
RP_PAIRING_URL	``	Admin only. Where the installing app is opened, shown as a way back to it. Optional.
RP_ADMIN_URL	``	Where you open the admin UI, e.g. https://192.168.1.5:8443. Optional: the proxy remembers the address you sign in at; this makes the first-run link exact before anyone has.
RP_TRUST_PORT	``	Host port that reaches the HTTP trust page if you publish it on something other than 80. Optional.
RP_DEBUG	``	Set to 1 for Caddy's full info-level log. Off by default so the log stays readable.

Volumes

Path	Description
/config	Admin state and secrets
/data	Certificates, ACME account and the internal CA

Ports

Port	Protocol	Description
80	TCP	HTTP: trust page and redirects to HTTPS
443	TCP	HTTPS: your hosts
8443	TCP	Admin UI (HTTPS)

First run

Start the container and read its log: it prints a link like https://<this machine>:8443/#token=XXXX-XXXX-XXXX-XXXX. Open it from another device on your network (the host itself cannot reach its own published ports). Setup asks for a password, which networks are home (only when the proxy is on more than one), how your names should look, one record on your router, and then helps each device trust the proxy. Installed from fjord, fjord opens this link for you.

The admin uses a self-issued certificate until setup is done, so the browser warns once. After setup it lives at https://proxy.<your ending> with a certificate your devices trust. The proxy remembers the address you sign in at, so reverse-proxy reset-password and a later first run print it; RP_ADMIN_URL makes the very first link exact too.

Names

Just for home (apps.lan, home.arpa, …): the proxy makes its own root certificate, restricted to that ending, so it can never vouch for any other site. The Trust page has steps for iPhone and iPad, Android, Mac, Windows, Linux and FreeBSD, with a QR code for phones. Visitors' devices see a warning until they trust it too.

A free name: pick "A free name from DuckDNS" in setup, sign in at duckdns.org, add a name, paste its token. Every app gets a name like radarr.you.duckdns.org that every device already trusts.

Your own domain (home.example.com): setup finds where its DNS is hosted and asks for a token that can edit its records. The proxy gets one wildcard certificate from Let's Encrypt for every name under it, so names never appear in the public certificate logs one by one. Nothing is reachable from the internet unless you open a name to it.

Per name, for apps that need it: more than one name for the same app; an app that serves HTTPS itself (its own certificate can be accepted); and "the service expects its own address", for apps such as UniFi that refuse a sign-in coming from another name.

Who can open what

A name is home network only unless you open it to the internet. Home is your private network (10.x, 172.16–31.x, 192.168.x), plus anything you add under Settings → Home network, such as a VPN (100.64.0.0/10 for Tailscale).

When the container is on several networks (fjord can give it one per VLAN so it reaches every app), setup and Settings → Home network list them. Devices on a ticked network can open the proxy and its home-only names. On an unticked one the proxy does not even answer, and its devices are never home, whatever your router does; the proxy still reaches the apps there. The network your browser is on stays ticked, so you cannot lock yourself out. From the command line: reverse-proxy listen 192.168.1.0/24 (or listen all); RP_LISTEN sets it in the compose.

Short links

Type go/radarr in a browser to open radarr.<your ending>, with any path after it; go/ alone lists every name. It takes one more record on your router (go pointing at the proxy); setup and Settings → Short links walk you through it. The word is yours to change, or turn off. The first time, type http://go/radarr with the http://: Safari and Firefox otherwise search the web for it.

fjord

Install the proxy from fjord and the two pair by themselves: fjord passes a key and a setup link, and its Finish setup button opens setup already verified. After that, fjord lists the apps that have no name yet and names the ones you pick, and keeps each name pointing at its app when the app's address changes.

Scripts and other apps

Anything that can make an HTTPS request can manage names. Make a key under Settings → Connected apps (or hand one to the proxy at install as RP_PAIRING_KEY) and send it as a bearer token; a key manages names and nothing else. The reference is the proxy's own https://<proxy>:8443/api/v1/openapi.json.

curl -sS https://192.168.1.5:8443/api/v1/hosts \
  -H "Authorization: Bearer rp_..." \
  -d '{"name":"radarr","target":{"address":"192.168.1.20","port":7878},"access":"home"}'

Inside the container the same works from the command line, no key needed:

podman exec reverse-proxy reverse-proxy hosts
podman exec reverse-proxy reverse-proxy hosts add radarr 192.168.1.20:7878
podman exec reverse-proxy reverse-proxy hosts remove radarr

Operations

• Forgot the password: podman exec reverse-proxy reverse-proxy reset-password prints a new setup link.
• Backup: Settings → Backup downloads one passphrase-encrypted file (names, settings, password, root certificate, DNS token). Restore it from the welcome screen of a fresh install.
• Keep /data: it holds the certificates Caddy issued. Losing /config loses the root certificate and the DNS token, and every device would have to trust the proxy again; a backup avoids that.
• Certificate trouble: the Names page shows a banner while a certificate is being obtained or when it failed, with the reason in plain words. Change the token under Settings → Ending and certificates.
• Non-default HTTP port: if you publish the trust page on something other than 80, set RP_TRUST_PORT so the Trust page's commands and QR code use it.

How it works

One container, two programs. Caddy runs as root so it can bind ports 80 and 443; the admin (the web UI and API) runs as bsd (PUID/PGID). They talk over unix sockets inside the container. The admin keeps one state file and writes Caddy's whole configuration from it: nothing is hand-edited, and a change Caddy refuses leaves the running one in place.

Architectures: amd64, aarch64 User: root (UID/GID via PUID/PGID, defaults to 1000:1000) Base: FreeBSD 15.1

---
